I'm not known for my super fast character design for Cartoon Animator. It's why I constantly look for short cuts in rigging characters because I get bored or distract... squirrel!
In this second post on rigging my first, complete G3-SVG vector character I'll run you through how I take my initial, 'inked' using Inkscape design, from part 1 of this series, and break it up into the key sprite body parts.
The main image for this post at the top of the article is a little deceptive as it shows a composite of my, mostly, complete character divided in half so you can see the underlying vector lines - totally for effect to create an interesting image.
Can You Learn Reallusion's Cartoon Animator 5 For Free Using Their 137 Official Youtube Video Tutorials Sorted Into A Logical Learning Order?
Imagine this image is still just the half image I traced and colored from last time. The next step is to create a joint layer and mark where all my joints (i.e. bone points) will be with my semi-transparent circular crosshairs that you can see in the image. But only on one side, remember. All of this will be mirrored when complete.
The purpose of these crosshairs is to mark the center point for the bone placement and then to create a circular region around the bone point that will create an almost seamless joint between each sprite.
The circular area, generally, should be as large as possible without going outside the boundary of the character's shape. Once the two sprites are pinned together the joint works like a hinge and should look fine in any natural pose of the character.
The Future Of Character Animation — Developer Blog
Note that I am designing this character to have bone hands but, as of writing this, each of the characters fingers are a full sprite. I've yet to separate them into the smaller joint segments.
If you recall I drew my character's body as one complete shape. My next step is to cut this up into sprites. It's a little tricky, and time consuming but I actually find this method easier than separating the character into sprites as I go.
It involves duplicating a line from my crosshairs that I use to cut the body sprite at the joint (see image 1 of Figure 1) using the 'Division' path function. Make sure you move the duplicate line to the same layer as the body shape if you're going to try this).
Ds Max Rigging Fundamentals
This slices the image in two where my crosshair line was (see image 2 of Figure 1). The crosshair line itself will vanish which is why I work with a duplicate.
Next I'll make a duplicate of the circle part of my crosshair, hide the section of the body I'm not working on just yet. In this case that's the upper leg (see image 3 of Figure 1).
I'll then color this circle with the same fill and line color of my body shape. I'll then make a duplicate of this circle that I'll use for the upper limb, once I've completed the lower limb (make sure the two circles are perfectly aligned).
Web Design Animation
Finally I'll combine my circle with the end of the body part I'm working on - in this case the right shank or lower right leg - by selecting the circle and the body part and executing a 'Union' path function on them (see image 4 of Figure 1).
I'll then use the duplicate circle and combine that with the upper part of the same limb - in this case the right thigh - giving a perfectly round end to that sprite too.
Note that if you're creating a character with outlines you can sometimes create the illusion of unbroken lines if you make one end of a sprite circular and the adjoining end flat but covering half of the circle (see Figure 2).
Rig A 2d Animated Character In Unity
Once I've divided up all my sprites I'll then go through and either add more highlights and shadows or fix any that I've already included so that they don't bleed over into my joint circle areas.
Minimising shading or highlights around your joints will help prevent any unexpected lines when limbs start moving around. Although if you study figure 2 (in the previous section) and apply those principles for the outlines to shadows and highlights, it can work quite seamlessly.
Once these are done I'm ready to mirror the entire design so I have a complete character. This is simply a case of selecting all my character parts, duplicating and flipping them vertically.
Animation: 2d Walk Cycle Using A Rig
After I've lined up the two halves of the character I'll join the two halves of the torso/hip sprite together with a Union path function. I'll do the same with the face, back hair, front hair, nose, and mouth.
Although it looks like I'm close to rigging the character I still need to create all my eye and mouth sprite expressions. I'm hoping that won't take too long given how much easier it is to modify vectors into different shapes.
Hopefully in the next post I'll be able to put all my sprites into Reallusion's Front Facing Character template and complete a first test animation.
